Below is our reflective material catalogue, outer shell reflective fabric catalogue and safety clothing catalogue, click on the cover to quickly overview most of the products we have now. You can either browse it online or download the catalogue in PDF format.

International Standards

For over 17 years, Chinastars has been providing high quality safety clothing to worldwide companies, and has become a influential enterprise in China safety industry by manufacturing high quality safety clothing and reflective fabrics. Chinastars provides a full range of safety clothing at excellent quality and competitive price. Including safety vests, reflective jackets, reflective rainwear, safety T-shirts, sweatshirts and reflective coveralls etc. to enhance the visibility for workers, police, firefighters, cyclists or pedestrians in low light conditions.

The International Organization for Standardization released on 28th June 2013 the new EN ISO 20471:2013 standard for the test methods and requirements of high visibility clothing. All EEC Type Examination Certificates based on EN 471 for high visibility clothing became invalid on 1st October 2013 regardless of any other mentioned validity date. Requirements are included for color, retro reflection and Physiological performance as well as for the minimum areas of visible material in high visibility clothing.

EN 20471 imposes requirements on visible workwear for employees in high-risk areas. The employees will be visible and safe at night, during the day, and from all angles. There are three classes which are related to risk assessment and are defined by the minimum areas of background fluorescent and retro-reflective material.

CLASS 1 performance provides less visibility than Class 2 or 3, but can be a good alternative for low risk duties and environments. It requires a minimum of 0.14m² of background material and 0.10m² of retro reflective material.

CLASS 2 performance is of intermediate level, requires a minimum of 0.50m² of background material and 0.13m² of retro reflective material.

CLASS 3 performance provide the highest level of conspicuity. A Class 3 garment is required to cover the torso and have sleeves with reflective bands or/and trouser legs with reflective bands. It requires a minimum of 0.80m² of background material and 0.20m² of retro material.

ANSI/ISEA 107-2015 is the American National Standard for High-Visibility Safety Apparel and Headwear. This standard provides an authoritative guide for the design, color, photometric and physical performance, use and test methods of high-visibility safety apparel including safety vests, hi vis jackets, bib coveralls, pants and harnesses. Based on different work environment, the standard classified the performance into three classes.

ANSI 107-2015 standard includes a “Type” structure that keeps off-road (“Type O”), roadway (“Type R”), and public safety (“Type P”) garments separate by application and work environment. The types are further broken down into classes 1, 2 or 3. Three classes help the user to choose the proper garments based on expected work environment risks.

TYPE O, CLASS 1 garments provides the minimum visibility to differentiate the wear from non-complex work environments where struck-by hazards will not be approaching at roadway speeds. It requires a minimum of 217 in² of background material and 155 in² of retro reflective or combined performance material.

TYPE R (Roadway use) garments are for occupational workers who are exposed to roadway traffic and who work in an environment with moving equipment/vehicles.

TYPE R, CLASS 2 garment is of intermediate level, for workers who will be exposed to traffic with speeds in excess of 25 mph. It requires a minimum of 775 in²(smallest size 540 in²) of background material and 201 in² of retro reflective or combined performance material.

TYPE R, CLASS 3 garments provide the highest level of safety, for workers who will be exposed to high speed traffic or reduced sight distances. It requires a minimum of 1240 in²(smallest size 1000 in²) of background material and 310 in² of retro reflective or combined performance material.

TYPE P, CLASS 2 garments provides additional options for emergency responders, incident responders and law enforcement in temporary traffic control (TTC) zones. It requires a minimum of 450 in² of background material and 201 in² of retro reflective or combined performance material.

CLASS E as a supplement type of ANSI 107, can be applied to rain pants, bib pants, shorts etc. It can Combine with a Class 2 vest for an ANSI Class 3 ensemble; or a Class 3 vest to attain a higher level visibility. It requires a minimum of 465 in² of background material and 109 in² of retro reflective or combined performance material.

AS/NZS 1906.4:2010 is the joint Australian/New Zealand Standard for retro reflective materials and devices for road traffic control purposes. It specifies the photometric, colorimetric and physical property requirements for high-visibility materials to be used in high visibility safety clothing, rather than the clothing themselves. The design requirements for high-visibility clothing are specified in AS/NZS 4602.1. For more detailed information, you’re welcomed to consult our service staff online or by email.

AS/NZS 4602.1 specifies the visual requirements for high visibility garments to ensure appropriate visibility for workers who may be exposed to traffic hazard in high risk situations. It also refers to another standard AS/NZS 1906.4:2010 for the reflective material that are used in the garments.

There are three classes relating to the application of the garments. Class D for daytime use only, Class N for nighttime use only, and Class D/N for day and/or night time use.

CLASS D garments made from fluorescent or other high visibility background materials without retro-reflective tape, are designed for daytime use only. The minimum area of high visibility background material shall be no less than 0.2 m² both front and back.

CLASS N garments are intended to provide the wearer with high visibility at night when illuminated by light, such as car headlight. It is manufactured with retro-reflective strips on a background fabric and are designed to make the wearer visible from all angles.

CLASS D/N garments combine fluorescent or other high visibility background materials with retro reflective tape, making them suitable for day and night use, or for workplace with low light conditions. Retro-reflective tape shall comply to AS/NZS 1906 and in specific tape configurations.

CAN/CSA Z96-15 describes the requirements for high visibility apparel for Canadian workers to be seen by vehicle operators, especially in low-light conditions or darkness. CSA lists three classes of garments based on body coverage provided.

CLASS 2 apparel has full coverage of the upper torso(front, back, sides and over the shoulders). Stripes/bands shall be composed of retro-reflective or combined performance materials, and are to be displayed to ensure 360° visibility.

CLASS 3 apparel provides the greatest body coverage and visibility. Apparel meets the same requirements as Class 2 with the addition of bands around both arms and legs.

BS EN 1150:1999 is the British-adopted European standards for non-professional use visibility clothing, which specifies the optical photometric, colorimetric and physical property performance of retro-reflective material, as well as the requirements for high visibility clothing designed for non-professional use and to be worn by juveniles or adults who want to enhance the visibility in any light conditions. Consult our service staff for detailed information into the standards.

Safety Clothing FAQs

Here are some common questions that we’re asked so we thought it might be helpful to post. For any other questions, you are welcomed to contact our service staff or send us emails.

Recommended FAQs

FAQs About Safety Clothing

  • 1. Are you a manufacturer?

    Yes. We are the leading manufacturer of both reflective material and safety clothing. So compared with other manufacturers, we have better quality control and highly cost effective products.

  • 2. Can we customize logo printing on the safety vest or reflective jacket?

    Yes. Logo printing is available with silk screen printing, offset printing or reflective logo heat transfers on front and back side of the safety vest.

  • 3. Can we customize different colors of reflective vests or jackets?

    Yes. Of course. Please provide us samples or Pantone No. of your wanted colors. But please note that some colors can't pass EN20471 or ANSI/ISEA 107 standard, in case you have requirements to pass standards, please check with our sales in advance.

  • 4. Does the fabric and reflective tape used on the safety vest/jacket comply to EN 20471 and ANSI/ISEA 107?

    Yes. The fluorescent yellow/orange fabric and reflective tape we used can all comply to European and American standards. In case you want to use other colors, please check with our sales in advance. Some colors esp. dark colors can't meet the requirements.

  • 5. Do you have the compliance certificate of safety vests/jackets to EN 20471 or ANSI/ISEA 107 standards?

    Since we have hundreds of different styles of safety vests/jackets. We are not able to make certificate for every designs. We only make certificates for several common styles. But we can provide you the compliance certificates of both fabric and reflective tapes, so that it will be much easier for you to make the clothing certificate.

  • 6. Do you have the safety vests/ jackets in stock?

    Yes. We keep stock for some regular styles to meet the requirements of some customers who need them urgently. Please check with our sales for more details.

  • 7. Can we customize different styles of safety vests/jackets?

    Yes. OEM or ODM is available. You can send us your sample vest or design artwork to customize your own safety vests/jackets.

  • 8. I don't have much experience in the size, label, logo designs etc. of safety vest/jacket, can you guide for me?

    Yes. We have our own design team and our sales is very experienced, we can provide you any guidance you need with patience.

  • 9. Do you have vests/jackets with pockets?

    Please kindly refer to the photos. And if needed, we can also add additional pockets.
